2016-2017 Kingbright Catalog - page 17

15
SMD LED
www.KingbrightUSA.com
Part Number Material lD
(nm) Lens Type
Iv (mcd)
@20mA
Viewing
Angle Dimensions
Min. Typ. 2q 1/2
AM23ESGC
GaAsP/GaP n 617
Water Clear
3 5
140°
SOT-23 Surface Mount LED Lamp (3mm x 1.3mm)
GaP n 568 5 10
AM23ESGW
GaAsP/GaP n 617
White
Diffused
3 5
140°
GaP n 568 5 9
APBDA3020SURKCGKC-GX
AlGaInP n 630
Water Clear
120 300
15°
3.0mm x 2.0mm x 2.8mm (Right Angle, Dome Lens)
AlGaInP n 570 120 300
APBDA3020CGKSYKC-GX
AlGaInP n 570
Water Clear
120 280
15°
AlGaInP n 590 400 700
APBDA3020QBDCGKC-GX
InGaN n 465
Water Clear
120 300
15°
AlGaInP n 570 120 300
APB3025EYC-F01
GaAsP/GaP n 617
Water Clear
3 8
120°
3.0mm x 2.5mm x 1.1mm (1109 Bi-Color)
GaAsP/GaP n 588 5 10
APB3025ESGC-F01
GaAsP/GaP n 617
Water Clear
3 8
120°
GaP n 568 8 15
APB3025SURKCGKC-F01
AlGaInP n 630
Water Clear
40 70
120°
AlGaInP n 570 20 60
APB3025YSGC-F01
GaAsP/GaP n 588
Water Clear
5 10
120°
GaP n 568 8 15
APBL3025ESGC-F01
GaAsP/GaP n 617
Water Clear
8 15
100°
3.0mm x 2.5mm x 1.4mm (1109 Bi-Color)
GaP n 568 12 20
APBL3025SURKCGK-F01
AlGaInP n 630
Water Clear
80 200
100°
AlGaInP n 570 55 120
APBL3025YSGC-F01
GaAsP/GaP n 588
Water Clear
5 15
100°
GaP n 568 12 20
MULTI-COLOR SMD LED
Units : mm(inch)
Tolerance : ±0.25(0.01)
AM23
Units : mm(inch)
Tolerance : ±0.2(0.008)
APBDA3020
Units : mm(inch)
Tolerance : ±0.2(0.008)
APB3025
Units : mm(inch)
Tolerance : ±0.2(0.008)
APBL3025
Multi-Color SMD LED
