06
SMD LED
Part Number Material lD
(nm) Lens Type
Iv (mcd)
@2mA
Viewing
Angle Dimensions
Min. Typ. 2q 1/2
APDA3020LSECK/J3-PF AlGaInP n 625 Water Clear 250 500 10°
3.0mm x 2.0mm x 2.8mm (1108 Right Angle)
APDA3020LSECK/J4-PF AlGaInP n 605 Water Clear 550 1000 10°
APDA3020LSYCK/J3-PF AlGaInP n 590 Water Clear 180 500 10°
APDA3020LZGCK InGaN n 525 Water Clear 250 600 10°
APDA3020LVBC/D InGaN n 470 Water Clear 80 150 10°
AA3021LSESK/J3-TR AlGaInP n 625 Water Clear 20 45 125°
3.0mm x 2.0mm x 1.3mm
AA3021LSESK/J4-TR AlGaInP n 605 Water Clear 30 60 125°
AA3021LSYSK/J3-TR AlGaInP n 590 Water Clear 20 45 125°
AA3021LZGSK InGaN n 525 Water Clear 80 180 125°
AA3021LVBS/D InGaN n 470 Water Clear 20 50 125°
APT3216LSECK/J3-PRV AlGaInP n 625 Water Clear 20 40 120°
3.2mm x 1.6mm x 0.75mm (1206)
APT3216LSECK/J4-PRV AlGaInP n 605 Water Clear 30 50 120°
APT3216LSYCK/J3-PRV AlGaInP n 590 Water Clear 15 25 120°
APT3216LZGCK InGaN n 525 Water Clear 20 50 120°
APT3216LVBC/D InGaN n 470 Water Clear 15 24 120°
AA3528LSESK/J3 AlGaInP n 625 Water Clear 30 50 120°
3.5mm x 2.8mm x 1.9mm
AA3528LSESK/J4 AlGaInP n 605 Water Clear 30 60 120°
AA3528LSYSK/J3 AlGaInP n 590 Water Clear 20 30 120°
AA3528LZGSK InGaN n 525 Water Clear 50 90 120°
AA3528LVBS/D InGaN n 470 Water Clear 30 45 120°
LOW CURRENT LED
Units : mm(inch)
Tolerance : ±0.2(0.008)
Units : mm(inch)
Tolerance : ±0.2(0.008)
Units : mm(inch)
Tolerance : ±0.2(0.008)
Units : mm(inch)
Tolerance : ±0.25(0.01)
AA3528L
APT3216L
AA3021L
APDA3020L
Low Current LED
