SMD LED
www.KingbrightUSA.com
Part Number Material lD
(nm) Lens Type
Iv (mcd)
@5mA
Viewing
Angle Dimensions
Min. Typ. 2q 1/2
APG1005VGC-T-5MAV InGaN n 527 Water Clear 30 70 145°
1.0mm x 0.5mm x 0.2mm (0402)
APG1005PBC-T-5MAV InGaN n 467 Water Clear 20 28 145°
APGA1602QBC/KA-5MAV InGaN n 463 Water Clear 8 20 130°(H)150°(V)
1.6mm x 0.2mm x 0.9mm (Right Angle)
Part Number Material lD
(nm) Lens Type
Iv (mcd)
@20mA
Viewing
Angle Dimensions
Min. Typ. 2q 1/2
APHHS1005SURCK AlGaInP n 630 Water Clear 40 70 120° 1.0mm x 0.5mm x 0.5mm (0402)
APHHS1005SECK AlGaInP n 601 Water Clear 80 150 120°
APHHS1005SYCK AlGaInP n 590 Water Clear 80 150 120°
APHHS1005CGCK AlGaInP n 570 Water Clear 20 50 120°
APHHS1005ZGCK InGaN n 525 Water Clear 200 400 120°
APHHS1005QBC/D InGaN n 465 Water Clear 40 60 120°
APG1005SEC/E-T AlGaInP n 624 Water Clear 20 75 120°
1.0mm x 0.5mm x 0.2mm (0402)
APG1005SEC-T AlGaInP n 605 Water Clear 40 90 120°
APG1005SYC-T AlGaInP n 589 Water Clear 55 100 120°
APG1005CGC-T AlGaInP n 571 Water Clear 12 35 120°
LOW CURRENT LED
Units : mm(inch)
Tolerance : ±0.1(0.004)
Units : mm(inch)
Tolerance : ±0.1(0.004)
APG1005-5MAV
APGA1602-5MAV
APHHS1005
TOP-EMITTING CHIP SMD LED
Units : mm(inch)
Tolerance : ±0.1(0.004)
APG1005
Units : mm(inch)
Tolerance : ±0.1(0.004)
Low Current LED, Top-Emitting Chip SMD LED
