THROUGH-HOLE LED
21
NOTES: 1. All dimensions are in millimeters(inches).
2. Tolerance is ±0.25mm(0.01") unless otherwise noted. www.KingbrightUSA.com
Part Number Material lD
(nm) Lens Type
Iv (mcd)
@10mA*20mA
Viewing
Angle Dimensions
Min. Typ. 2q 1/2
WP4060ED GaAsP/GaP n 617 Orange Diffused 4 8 70° 1.8mm Round
WP4060ID GaAsP/GaP n 617 Red Diffused 4 8 70°
WP4060SRD GaAlAs n 640 Red Diffused *30 *80 70°
WP4060YD GaAsP/GaP n 588 Yellow Diffused 4 8 70°
WP4060GD GaP n 568 Green Diffused 6 12 70°
WP710A10ID GaAsP/GaP n 617 Red Diffused 10 20 40° T-1 (3mm) Round
WP710A10IT GaAsP/GaP n 617 Red Transparent 12 30 34°
WP710A10EC GaAsP/GaP n 617 Water Clear 12 30 34°
WP710A10ND GaAsP/GaP n 602 Orange Diffused 10 20 40°
WP710A10NC GaAsP/GaP n 602 Water Clear 12 30 34°
WP710A10YD GaAsP/GaP n 588 Yellow Diffused 8 15 40°
WP710A10YT GaAsP/GaP n 588 Yellow Transparent 10 30 34°
WP710A10YC GaAsP/GaP n 588 Water Clear 10 30 34°
WP710A10GD GaP n 568 Green Diffused 10 25 40°
WP710A10GT GaP n 568 Green Transparent 12 40 34°
WP710A10GC GaP n 568 Water Clear 12 40 34°
WP710A10SRC/D GaAlAs n 640 Water Clear *120 *240 34°
WP710A10SRD/D GaAlAs n 640 Red Diffused *70 *140 40°
WP710A10SRD/E GaAlAs n 640 Red Diffused *80 *150 40°
WP710A10SRD/F GaAlAs n 640 Red Diffused *90 *160 40°
WP710A10SRC/J4 AlGaInP n 640 Water Clear *750 *1500 34°
WP710A10SRD/J4 AlGaInP n 640 Red Diffused *200 *500 40°
WP710A10SURC/E AlGaInP n 630 Water Clear *180 *400 34°
WP710A10SEC/J3 AlGaInP n 625 Water Clear *1300 *2400 34°
WP710A10SECK/J3 AlGaInP n 625 Water Clear *1000 *1600 34°
WP710A10SEC/E AlGaInP n 621 Water Clear *400 *900 34°
WP710A10SECK/J4 AlGaInP n 605 Water Clear *1500 *3000 34°
WP710A10SED AlGaInP n 601 Orange Diffused *300 *650 40°
WP710A10SET AlGaInP n 601 Orange Transparent *350 *800 34°
WP710A10SEC AlGaInP n 601 Water Clear *350 *800 34°
WP710A10SYD AlGaInP n 590 Yellow Diffused *480 *900 40°
WP710A10SYT AlGaInP n 590 Yellow Transparent *700 *1200 34°
WP710A10SYC AlGaInP n 590 Water Clear *700 *1200 34°
WP710A10SYC/J3 AlGaInP n 590 Water Clear *1600 *2800 34°
WP710A10SYCK/J3 AlGaInP n 590 Water Clear *1600 *2600 34°
WP710A10SGD GaP n 568 Green Diffused *18 *40 40°
WP710A10SGC GaP n 568 Water Clear *30 *60 34°
WP710A10CGCK AlGaInP n 570 Water Clear *150 *330 34°
WP710A10ZGCK InGaN n 525 Water Clear *5000 *8000 34°
WP710A10ZGC/G InGaN n 525 Water Clear *8000 *14000 34°
WP710A10QBC/D InGaN n 465 Water Clear *900 *1600 20°
WP710A10VBC/D InGaN n 470 Water Clear *2100 *3700 20°
WP3A10HD GaP n 635 Red Diffused 0.6 1.8 60°
T-1 (3mm) Round
WP3A10ID GaAsP/GaP n 617 Red Diffused 6 15 60°
WP3A10YD GaAsP/GaP n 588 Yellow Diffused 8 15 60°
WP3A10GD GaP n 568 Green Diffused 12 25 60°
ROUND LED
WP4060
WP710A10
WP3A10
