SMD DISPLAY
33
NOTES: 1. All dimensions are in millimeters(inches).
2. Tolerance is ±0.25mm(0.01") unless otherwise noted. www.KingbrightUSA.com
Part Number
Material lD
(nm)
Iv (ucd)
@10mA Dimensions
Common Anode Common Cathode Min. Typ.
ACSA56-51SURKWA
ACDA56-51SURKWA - AlGaInP n 630 21000 76000
0.56 inch (14.22mm), Gray Face, White Segment
ACSA56-51SYKWA
ACDA56-51SYKWA - AlGaInP n 590 52000 117000
ACSA56-51CGKWA
ACDA56-51CGKWA - AlGaInP n 570 14000 26000
ACSA56-51PBWA/A
ACDA56-51PBWA/A - InGaN n 465 1400 4000
ACSA08-51SURKWAACSC08-51SURKWAAlGaInP n 630 21000 47000
0.8 inch (20.32mm), Gray Face, White Segment
ACSA08-51SEKWA ACSC08-51SEKWAAlGaInP n 601 31000 82000
ACSA08-51SYKWA ACSC08-51SYKWAAlGaInP n 590 31000 93000
ACSA08-51CGKWA ACSC08-51CGKWAAlGaInP n 570 9000 18000
ACSA08-51ZGKWA ACSC08-51ZGKWA InGaN n 525 52000 118000
ACSA08-51QBWA/DACSC08-51QBWA/DInGaN n 465 3600 8700
7-SEGMENT SMD DISPLAY
ALPHANUMERIC SMD DISPLAY
Part Number
Material lD
(nm)
Iv (ucd)
@10mA Dimensions
Common Anode Common Cathode Min. Typ.
ACPSA04-41SURKWAACPSC04-41SURKWAAlGaInP n 630 14000 36000
0.4 inch (10.16mm), Gray Face, White Segment
ACPSA04-41SEKWAACPSC04-41SEKWAAlGaInP n 601 21000 44000
ACPSA04-41SYKWAACPSC04-41SYKWAAlGaInP n 590 21000 46000
ACPSA04-41CGKWAACPSC04-41CGKWAAlGaInP n 570 5600 11000
ACSA56-51
ACPSX04-41
ACSX08-51
ACDA56-51
7-Segment SMD Display,
Alphanumeric SMD Display
