2016-2017 Kingbright Catalog - page 29

THROUGH-HOLE LED
27
NOTES: 1. All dimensions are in millimeters(inches).
2. Tolerance is ±0.25mm(0.01") unless otherwise noted. www.KingbrightUSA.com
Part Number Material lD
(nm) Lens Type
Iv (mcd)
@20mA
Viewing
Angle Dimensions
Min. Typ. 2q 1/2
WP3VEYW
GaAsP/GaP n 617
White Diffused
10 30
60°
T-1 (3mm) Round
GaAsP/GaP n 588 10 15
WP3VEGW
GaAsP/GaP n 617
White Diffused
10 30
60°
GaP n 568 20 40
WP3VGYW
GaP n 568
White Diffused
15 40
60°
GaAsP/GaP n 588 10 15
WP57IID GaAsP/GaP n 617 Red Diffused 4 12 60° T-1 3/4 (5mm) Round
GaAsP/GaP n 617 4 12
WP57YYD GaAsP/GaP n 588 Yellow Diffused
6 12
60°
GaAsP/GaP n 588 6 12
WP57GGD
GaP n 568 Green Diffused
8 20
60°
GaP n 568 8 20
WP57EYW
GaAsP/GaP n 617
White Diffused
6 14
60°
GaAsP/GaP n 588 4 10
WP57EGW
GaAsP/GaP n 617
White Diffused
6 14
60°
GaP n 568 12 30
WP57GYW
GaP n 568
White Diffused
12 30
60°
GaAsP/GaP n 588 4 10
WP59EYW GaAsP/GaP n 617 White Diffused 20 40 60° T-1 3/4 (5mm) Round
GaAsP/GaP n 588 20 40
WP59EGW GaAsP/GaP n 617 White Diffused 20 40 60°
GaP n 568 20 60
WP59GYW GaP n 568 White Diffused 50 100 60°
GaAsP/GaP n 588 20 40
WP59SURKCGKW AlGaInP n 630 White Diffused 80 200 60°
AlGaInP n 570 80 180
WP59EYC GaAsP/GaP n 617 Water Clear 50 100 24°
GaAsP/GaP n 588 40 80
WP59EGC GaAsP/GaP n 617 Water Clear 50 100 24°
GaP n 568 50 120
WP59GYC GaP n 568 Water Clear 50 120 24°
GaAsP/GaP n 588 40 80
WP154A4SUREQBFZGKC
AlGaInP n 630
Water Clear
200 400
50°
T-1 3/4 (5mm) Full Color
InGaN n 465 400 900
InGaN n 525 900 1600
WP154A4SUREQBFZGKW
AlGaInP n 630
White Diffused
120 250
60° InGaN n 465 300 500
InGaN n 525 600 1300
WP799EGW
GaAsP/GaP n 617
White Diffused
20 40
50°
8mm Round
GaP n 568 20 50
MULTI-COLOR LED
WP3V
WP57
WP59
WP154A4
WP799
Multi-color LED
