NOTES: 1. All dimensions are in millimeters(inches).
2. Tolerance is ±0.25mm(0.01") unless otherwise noted.
THROUGH-HOLE DISPLAY
DUAL DIGIT 7-SEGMENT THROUGH-HOLE DISPLAY
Part Number
Material
l
D
(nm)
Iv (ucd)
@10mA
Dimensions
Common Anode Common Cathode
Min.
Typ.
AlGaInP
n
630 31000 85000
0.56 inch (14.22mm), Gray Face, White Segment
AlGaInP
n
590 52000 130000
AlGaInP
n
570 14000 35000
AlGaInP
n
630 52000 100000
0.56 inch, (14.22mm), Gray Face, White Segment
AlGaInP
n
590 52000 120000
AlGaInP
n
570 14000 23000
AlGaInP
n
630 31000 75000
0.8 inch (20.32mm), Gray Face, White Segment
AlGaInP
n
590 52000 94000
AlGaInP
n
570 14000 38000
DX56-11
DX56-51
DX08
Dual
Digit 7-Segment Through-hole Display
