Kingbright proudly introduces the latest addition to “HELI” Series—HELI-R SMD LED available in top emitting industry standard packages that feature high luminosity output while maintaining energy efficient requirements all engineered with reverse mount technology. Reverse mount configuration provides advantages in designs with space and height constraints and facilitates streamlining production using automatic placement equipment.
To build upon the success of our market driven “HELI” series, Kingbright expands lineup further by providing industry standard 1205, 1206, and PLCC-2 SMD packages in reverse mount options. In compliance with RoHS and REACH regulations, HELI-R LED series is available in full color spectrum, and contains single, bi-color and full color options with superior performances while operating at low current (20 mA typical). An exceptional series for backlighting, home automation, icon illumination, medical equipment, consumer devices and battery operated applications.
This series offers PLCC-2 packages equipped with z-bend leads available in all standard colors including bi-color and full color combinations. In addition, standard 1206 packages are presented with flat-top, dome, and inner dome lens options to provide various intensities and emission angles ranging from 30° to 140° Viewing Angle. To complete this series, a matching infrared emitter/detector pair is also available in reverse mount 1206 SMD package option.
To learn more about Kingbright’s HELI-R SMD LEDs, please visit here for more information.
| Photo | Part Number / Description | Color | Wavelength | Luminous Intensity | Viewing Angle | Data Sheet | 3D Spec† | ||
|---|---|---|---|---|---|---|---|---|---|
| Min. | Typ. | Unit | |||||||
 | AA3528QBS/D09 3.5X2.8MM BLUE PLCC2 SMD LED | 465nm | 80 | 150 | mcd @20mA | 120° |  | .SLDPRT .PRO .IGES .STEP | |
| AA3528SECKT/J309 3.5X2.8MM RED PLCC2 SMD LED | 625nm | 500 | 700 | mcd @20mA | 120° | | .SLDPRT .PRO .IGES .STEP | |
| AA3528SECKT09 3.5X2.8MM ORANGE PLCC2 SMD LED | 605nm | 120 | 230 | mcd @20mA | 120º | | .SLDPRT .PRO .IGES .STEP | |
| AA3528SURCKT09 3.5X2.8MM RED PLCC2 SMD LED | 630nm | 55 | 100 | mcd @20mA | 120º | | .SLDPRT .PRO .IGES .STEP | |
| AA3528SYCKT/J309 3.5X2.8MM YELLOW PLCC2 SMD LED | 590nm | 400 | 600 | mcd @20mA | 120° | | .SLDPRT .PRO .IGES .STEP | |
| AA3528SYCKT09 3.5X2.8MM YELLOW PLCC2 SMD LED | 590nm | 120 | 250 | mcd @20mA | 120º | | .SLDPRT .PRO .IGES .STEP | |
| AA3528ZGCKT09 3.5X2.8MM GREEN PLCC2 SMD LED | 525nm | 500 | 1000 | mcd @20mA | 120º | | .SLDPRT .PRO .IGES .STEP | |
 | AAA3528RBGS/08-09 3.5X2.8MM RGB REVERSE MOUNT PLCC4 SMD LED | 630nm 465nm 525nm | 55 / 55 / 500 | 110 / 100 / 700 | mcd @20mA | 120º | | .SLDPRT .PRO .IGES .STEP | |
| AAA3528SURKCGKC09 3.5X2.8MM RED/GREEN REVERSE MOUNT PLCC4 SMD LED | 630nm 570nm | 55 / 40 | 100 / 80 | mcd @20mA | 120º | | .SLDPRT .PRO .IGES .STEP | |
 | APTB3212SURKCGKC-01 3.2X1.2MM BI-COLOR RED/GREEN REVERSE MOUNT SMD LED | 630nm 570nm | 40 / 20 | 80 / 50 | mcd @20mA | 130º | | .SLDPRT .PRO .IGES .STEP | |
 | APTBD3216SURKCGKC-01 3.2X1.6MM (1206) BI-COLOR RED/GREEN SMD LED | 630nm 570nm | 300 / 120 | 600 / 250 | mcd @20mA | 30° | | .SLDPRT .PRO .IGES .STEP | |
| APTBD3216SURKSYKC-01 3.2X1.6MM (1206) BI-COLOR RED/YELLOW SMD LED | 630nm 590nm | 300 / 200 | 600 / 450 | mcd @20mA | 30° | | .SLDPRT .PRO .IGES .STEP | |
 | APTL3216CGCK-01 3.2X1.6MM (1206) GREEN REVERSE MOUNT SMD LED | 570nm | 55 | 100 | mcd @20mA | 80° | | .SLDPRT .PRO .IGES .STEP | |
| APTL3216QBC/D-01 3.2X1.6MM (1206) BLUE REVERSE MOUNT SMD LED | 465nm | 120 | 250 | mcd @20mA | 80° | | .SLDPRT .PRO .IGES .STEP | |
| APTL3216SECK-01 3.2X1.6MM (1206) ORANGE REVERSE MOUNT SMD LED | 605nm | 200 | 350 | mcd @20mA | 80° | | .SLDPRT .PRO .IGES .STEP | |
| APTL3216SURCK-01 3.2X1.6MM (1206) RED REVERSE MOUNT SMD LED | 630nm | 120 | 230 | mcd @20mA | 80° | | .SLDPRT .PRO .IGES .STEP | |
| APTL3216SYCK01 3.2X1.6MM (1206) YELLOW REVERSE MOUNT SMD LED | 590nm | 200 | 350 | mcd @20mA | 80° | | .SLDPRT .PRO .IGES .STEP | |
| APTL3216ZGCK-01 3.2X1.6MM (1206) GREEN REVERSE MOUNT SMD LED | 525nm | 700 | 1000 | mcd @20mA | 80° | | .SLDPRT .PRO .IGES .STEP | |
 | APTR3216CGCK 3.2X1.6MM (1206) GREEN REVERSE MOUNT SMD LED | 570nm | 20 | 50 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
| APTR3216F3C 3.2X1.6MM (1206) INFRARED REVERSE MOUNT SMD LED | 940nm | 0.8 | 2 | Po (mW/sr) @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
 | APTR3216P3BT 3.2X1.6MM (1206) PHOTOTRANSISTOR SMD LED | N/A | N/A | N/A | N/A | | .SLDPRT .PRO .IGES .STEP | ||
| APTR3216QBC/D 3.2X1.6MM (1206) BLUE REVERSE MOUNT SMD LED | 465nm | 40 | 100 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
| APTR3216SECK/J3-PRV 3.2X1.6MM (1206) RED REVERSE MOUNT SMD LED | 625nm | 200 | 350 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
| APTR3216SECK 3.2X1.6MM (1206) ORANGE REVERSE MOUNT SMD LED | 605nm | 80 | 180 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
| APTR3216SURCK 3.2X1.6MM (1206) RED REVERSE MOUNT SMD LED | 630nm | 40 | 80 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
| APTR3216SYCK/J3-PRV 3.2X1.6MM (1206) YELLOW REVERSE MOUNT SMD LED | 590nm | 200 | 320 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
| APTR3216SYCK 3.2X1.6MM (1206) YELLOW REVERSE MOUNT SMD LED | 590nm | 80 | 150 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
 | APTR3216-VFX 3.2X1.6MM (1206) PURPLE SMD LED (X=0.19, Y=0.05) | X=0.19, Y=0.05 | 55 | 100 | mcd @20mA | 160° | | .SLDPRT .PRO .IGES .STEP | |
| APTR3216ZGCK 3.2X1.6MM (1206) GREEN REVERSE MOUNT SMD LED | 525nm | 300 | 550 | mcd @20mA | 140º | | .SLDPRT .PRO .IGES .STEP | |
† Lens colors in 3D files are for display purpose only, please refer to Datasheet for precise lens type and color.
† In case of discrepancy, dimensions in 2D PDF files supersede data in 3D specification files.
