TECHNICAL NOTES
61
SMD TAPE SPECIFICATIONS
APTD3216
PACKAGE: 2000PCS / REEL
APTD3216SRCPRV
PACKAGE: 2000PCS / REEL
APTF1616
PACKAGE: 2000PCS / REEL
APTL3216
PACKAGE: 2000PCS / REEL
APTR3216
PACKAGE: 2000PCS / REEL
APTB1615
PACKAGE: 2000PCS / REEL
APTD1608
PACKAGE: 2000PCS / REEL
AA2214
AA2810A
AA3021
RECOMMENDED SOLDERING PATTERN
SMD Tape Specifications, Recommended Soldering Pattern
NOTES: 1. All dimensions are in millimeters.
2. Tolerance is ±0.1mm unless otherwise noted.
