Absolute maximum ratings
(T
A
=25°
C
)
SYK/TT
Super Bright
Yellow
PB/TT
Blue
QB/KA
Blue
QB/D
Blue
QB/F
Blue
VB/D
Blue
Unit
(AlGaInP)
(InGaN)
(InGaN)
(InGaN)
(InGaN)
(InGaN)
n
n
n
n
n
n
Reverse voltage
V
R
5
5
5
5
5
5
V
Forward current
I
F
25
10
20
30
30
30
mA
Forward current (Peak)
1/10 Duty Cycle,
0.1ms Pulse Width
i
FS
120
50
100
150
150
100
mA
Power dissipation
P
D
60
35
70
120
120
120
mW
LED LAMPS:
Operating temperature
T
A
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
Storage temperature
T
STG
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
LED DISPLAYS:
Operating temperature
T
A
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
Storage temperature
T
STG
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
Operating Characteristics
SYK/TT
Super Bright
Yellow
PB/TT
Blue
QB/KA
Blue
QB/D
Blue
QB/F
Blue
VB/D
Blue
Unit
(AlGaInP)
(InGaN)
(InGaN)
(InGaN)
(InGaN)
(InGaN)
Forward voltage (typ.)
n
n
n
n
n
n
I
F
=20mA
V
F
2.05
/
3.1
3.3
3.3
3.3
V
I
F
=10mA
2.01
3.0
2.95
3.0
3.0
3.0
I
F
=2mA
1.94
2.8
2.65
2.65
2.65
2.65
Forward voltage (max.)
I
F
=20mA, 10mA, 2mA
V
F
2.4
3.5
3.5
4.0
4.0
4.0
V
Reverse current
V
R
=5V
I
R
10
50
50
50
50
50
uA
Peak Emission Wavelength
I
F
=20mA, 10mA, 2mA
l
p
591
461
460
460
460
465
nm
Dominant Wavelength
I
F
=20mA, 10mA, 2mA
l
D
589
467
463
465
465
470
nm
Spectral line half-width
I
F
=20mA, 10mA, 2mA
Dl
1/2
15
22
25
25
25
22
nm
Capacitance
V
F
=0V,f=1MHZ
C
25
110
100
100
100
100
pF
