2016-2017 Kingbright Catalog - page 65

TECHNICAL NOTES

63

www.KingbrightUSA.com

APBDA3020

APD3224

APDA3020

AM23-F,AM23xx

AM2520xxx03

AM2520xxx09

APA1606

APA2107

APA3010, APBA3010

RECOMMENDED SOLDERING PATTERN

APB3025, APBL3025

APB3227

APBD3224

ACSX08-51

ACSA56-51

ACSX56-41

Recommended Soldering Pattern

NOTES: 1. All dimensions are in millimeters.

2. Tolerance is ±0.1mm unless otherwise noted.
