TECHNICAL NOTES
68
Absolute maximum ratings
(T
A
=25°
C
)
CGK
Green
CGK/T
Green
VG/TT
Green
ZGK
Green
ZG
Green
ZG/G
Green
Unit
(AlGaInP)
(AlGaInP)
(InGaN)
(InGaN)
(InGaN)
(InGaN)
n
n
n
n
n
n
Reverse voltage
V
R
5
5
5
5
5
5
V
Forward current
I
F
30
30
10
25
25
30
mA
Forward current (Peak)
1/10 Duty Cycle,
0.1ms Pulse Width
i
FS
150
150
50
150
150
100
mA
Power dissipation
P
D
75
78
35
102.5
102.5
120
mW
LED LAMPS:
Operating temperature
T
A
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
Storage temperature
T
STG
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
LED DISPLAYS:
Operating temperature
T
A
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
Storage temperature
T
STG
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
- 40~+85
°
C
Operating Characteristics
CGK
Green
CGK/T
Green
VG/TT
Green
ZGK
Green
ZG
Green
ZG/G
Green
Unit
(AlGaInP)
(AlGaInP)
(InGaN)
(InGaN)
(InGaN)
(InGaN)
Forward voltage (typ.)
n
n
n
n
n
n
I
F
=20mA
V
F
2.1
2.1
/
3.3
3.3
3.2
V
I
F
=10mA
2.0
1.95
3.2
3.0
3.0
3.05
I
F
=2mA
1.9
1.8
2.8
2.65
2.65
2.8
Forward voltage (max.)
I
F
=20mA, 10mA, 2mA
V
F
2.5
2.6
3.5
4.1
4.1
4.0
V
Reverse current
V
R
=5V
I
R
10
10
50
50
50
50
uA
Peak Emission Wavelength
I
F
=20mA, 10mA, 2mA
l
p
574
574
518
515
515
520
nm
Dominant Wavelength
I
F
=20mA, 10mA, 2mA
l
D
570
570
527
525
525
525
nm
Spectral line half-width
I
F
=20mA, 10mA, 2mA
Dl
1/2
20
15
35
35
30
35
nm
Capacitance
V
F
=0V,f=1MHZ
C
15
15
100
45
45
100
pF
