 | 3.5X2.8MM R/G REVERSED MOUNT SMD LED | Emitting Color : Red / Green
Material : AlGaInP,AlGaInP
Lens Type : Water Clear | | | | | | |
| | | Material | Color / Wavelength | Lens Type | Luminous Intensity | Viewing Angle | Data
Sheet | 3D Spec† | | Min. | Typ. | Unit | AlGaInP
AlGaInP | 630nm
570nm | Water Clear | 55
40 | 100
80 | mcd @20mA | 120º |
| .SLDPRT .PRO
.IGES .STEP |
|
† For all 3D specs viewing, save files in local drive and open with your 3D application.
† Lens colors in 3D files are for display purpose only, please refer to Datasheet for precise lens type and color.
† In case of discrepancy, dimensions in Datasheet supersede 3D spec.
| Product Features - Industry standard PLCC-4 package
- 3.5 x 2.8 x1.9mm (LxHxW) SMT LED
- Each color can be controlled separately
- Suitable for all SMT assembly and solder process
- Package : 2000pcs / reel
- RoHS compliant
Applications - Ideal for backlighting
- Illuminating icon
- Marker lights (e.g. Steps, exit ways, etc)
- Available in various color combinations
|
|
|
|
