HELIUM ushers in a new generation of ultra-compact SMD LEDs, featuring a miniature 0.65 x 0.35 x 0.20 mm footprint that enables innovative designs without space limitations. Built with advanced AlGaInP and InGaN chip technologies, HELIUM delivers exceptional brightness in a remarkably small package.
Perfectly suited for wearables, portable consumer electronics, disposable healthcare devices, enterprise solutions, industrial automation, and robotic systems, HELIUM integrates seamlessly into space-constrained applications. Its high compatibility with automated placement systems allows it to be handled just like standard 0201 passive components, streamlining assembly and production.
| Photo | Part Number / Description | Color | Wavelength | Luminous Intensity | Viewing Angle | Data Sheet | 3D Spec† | ||
|---|---|---|---|---|---|---|---|---|---|
| Min. | Typ. | Unit | |||||||
 | APG0201CGC-TT 0.6X0.3MM (0201) GREEN SMD LED | 571nm | 6 | 15 | mcd @10mA | 140º |  |  | |
| APG0201SEC-E-TT 0.6X0.3MM (0201) RED SMD LED | 624nm | 15 | 40 | mcd @10mA | 140º | | | |
| APG0201SEC-TT 0.6X0.3MM (0201) ORANGE SMD LED | 605nm | 20 | 50 | mcd @10mA | 140º | | | |
| APG0201SURC-TT 0.6X0.3MM (0201) RED SMD LED | 631nm | 10 | 35 | mcd @10mA | 140º | | | |
| APG0201SYC-TT 0.6X0.3MM (0201) YELLOW SMD LED | 589nm | 10 | 30 | mcd @10mA | 140º | | | |
| APG0201VBC/A-5MAV 0.6X0.3MM (0201) BLUE SMD LED | 468nm | 30 | 60 | mcd @5mA | 140º | | | |
 | APG0201VWF-A1-5MAV 0.6X0.3MM (0201) WHITE SMD LED (X=0.31, Y=0.31) | Cool White | 180 | 320 | mcd @5mA | 140º | | | |
| APG0201ZGC-5MAV 0.6X0.3MM (0201) GREEN SMD LED | 525nm | 180 | 280 | mcd @5mA | 140º | | | |
† Lens colors in 3D files are for display purpose only, please refer to Datasheet for precise lens type and color.
† In case of discrepancy, dimensions in 2D PDF files supersede data in 3D specification files.
