Chameleon RGB+IC series

Kingbright reveals its first RGB+IC – an addressable intelligent control LED in PLCC-6 package

Los Angeles, CA – Kingbright introduces RGB+IC series that integrates the control circuit and RGB chip in a 5050 package for complete control of pixel points. The data protocol uses unipolar NRZ communication code that enables a simple circuit, small size and convenient installation.

The control circuit and the LED shares the same power source with built-in electric reset and power lost reset circuit. Our RGB+IC SMD LED can achieve 256- level grayscale with each color being controlled individually. Kingbright RGB+IC is ideal for decorative and entertainment lighting applications, full color soft light strip, commercial and residential architectural lighting, signage application and etc. Kingbright RGB+IC PLCC 6 package accomplishes a higher moisture sensitivity level rating at MSL 3 to provide more durability and flexibility to customer’s design and production.

To learn more about Kingbright RGB+IC LEDs selections, please visit Chameleon RGB+IC page for more information.

Product Features
  • The control and the LED share the same power source
  • Intelligent protection against reverse connection
  • Built-in electric reset and power lost reset circuit
  • 256-level grayscale adjustable circuit
  • Built-in signal reshaping circuit
  • Cascade port transmission signal by single line
  • Moisture sensitivity level: 3
  • RoHS compliant

Applications
  • Decorative and entertainment lighting
  • Full-Color module, full color soft lights a lamp strip
  • Commercial and residential architectural lighting
  • Signage applications
PhotoPart Number / DescriptionColorWavelengthLuminous IntensityViewing
Angle
Data
Sheet
3D Spec
Min.Typ.Unit
AAAF5050-MC-K12
5.0X5.0MM RGB PLCC6 SMD LED WITH BUILT-IN IC
625nm
525nm
465nm
200 / 400 / 80360 / 600 / 150mcd @ Vdd=5V 120°Data sheet.SLDPRT
.PRO
.IGES
.STEP

† Lens colors in 3D files are for display purpose only, please refer to Datasheet for precise lens type and color.
† In case of discrepancy, dimensions in 2D PDF files supersede data in 3D specification files.
