Redefining Display LED Integration – No Mounting Adapter Needed

Kingbright proudly introduces the integrated Single-digit Right Angle Display LED available in both green and blue. Unlike standard numeric displays, this common anode configuration through-hole display is designed to stand upright on a PCB—no external mounting hardware required. That means one less part to source, and one less constraint in your design.

Unlike traditional flat-on-board display LEDs, this component was intentionally engineered for vertical orientation, giving design engineers greater flexibility and faster assembly—ideal for compact or front-facing display applications.

Key Specifications:

• Digit Height: 0.32 inch (8 mm)
• Colors & Wavelengths:
  • Blue: 465 nm
  • Green: 525 nm and 568 nm
• Available in Iv@10mA & 2mA low current options for energy-efficient designs
• Compact Package: Black face, white segment, right-hand decimal, with easy mounting on P.C. boards or sockets
• Operating Temperature: -40°C to +85°C
• RoHS Compliant

Perfect for smart appliances, industrial readouts, and space-conscious displays where clean vertical visibility matters.

Cut extra components out of your design—this LED can stand on its own.

Photo	Part Number / Description	Color	Wavelength	Luminous Intensity			Viewing Angle	Data Sheet	3D Spec†
				Min.	Typ.	Unit
	SA32-61GWB-2BCB 0.32" RIGHT ANGLE 7-SEGMENT GREEN LED DISPLAY		568nm	2200	5000	ucd @10mA	N/A
	SA32-61LZGKWB-2BCB  0.32" RIGHT ANGLE 7-SEGMENT LOW CURRENT GREEN LED DISPLAY		525nm	21000	38000	ucd @2mA	N/A
	SA32-61QBWB-2BCB 0.32" RIGHT ANGLE 7-SEGMENT BLUE LED DISPLAY		465nm	5600	13000	ucd @10mA	N/A
	SA32-61ZGKWB-2BCB   0.32" RIGHT ANGLE 7-SEGMENT GREEN LED DISPLAY		525nm	52000	111000	ucd @10mA	N/A
