Boost Output with Kingbright’s New High-Efficiency 940nm IR LEDs

Drive Peak Performance: High-Power IR LEDs for Demanding 940nm Applications

Maximize your system’s output with Kingbright’s new High-Efficiency IR LEDs, designed to handle higher drive current and deliver significantly greater radiant intensity at 940nm. Built for performance-critical applications, these LEDs offer the high-power output and fast switching speed required by today’s most advanced systems.

Whether you’re designing for high-speed communication, precision sensing, or industrial-grade reliability, our 940nm IR LEDs provide the power and responsiveness to elevate your application.

Key ADVANTAGES:

• Higher Drive Current Capability – Supports increased current input for more powerful IR emission
• Greater Radiant Intensity – Delivers stronger IR output for improved system performance
• Fast Switching Times – Ideal for real-time, high-speed applications
• 940nm Wavelength Optimized – Perfect for detectors and systems tuned to 940nm
• Drop-In Ready – Standard package sizes ensure easy system upgrades
• Built for Rugged Environments – Proven reliability for industrial, commercial, and security uses

Ideal for Applications Including:

• Industrial Automation & Robotics
• High-Speed IR Data Transmission
• Surveillance & Security Systems
• Machine Vision & Object Detection
• Remote Control Systems

Photo	Part Number / Description	Color	Wavelength	Luminous Intensity			Viewing Angle	Data Sheet	3D Spec†
				Min.	Typ.	Unit
	AM2520SF3C03-100MAV 2.5X2.0MM HIGH RADIANCE & HIGH SPEED INFRARED SMD LED GULL WING		940nm	80	120	Po (mW/sr) @100mA	20°
	AM2520SF3C09-100MAV 2.5X2.0MM HIGH RADIANCE & HIGH SPEED INFRARED SMD LED Z-BEND		940nm	80	120	Po (mW/sr) @100mA	20°
	APA3010SF3C-100MAV 3.0X1.0MM (1104) RIGHT ANGLE HIGH RADIANCE & HIGH SPEED INFRARED SMD LED		940nm	8	11	Po (mW/sr) @100mA	160°
	APDA3020SF3C-100MAV 3.0X2.0MM RIGHT ANGLE HIGH RADIANCE & HIGH SPEED INFRARED SMD LED		940nm	55	100	Po (mW/sr) @100mA	10°
	APT1608SF3C-100MAV 1.6X0.8MM (0603) HIGH RADIANCE & HIGH SPEED INFRARED SMD LED		940nm	8	11	Po (mW/sr) @100mA	150°
	APTD1608SF3C-100MAV 1.6X0.8MM (0603) HIGH RADIANCE & HIGH SPEED INFRARED SMD LED		940nm	12	30	Po (mW/sr) @100mA	120°
	APTD3216SF3C-100MAV 3.2X1.6MM (1206) HIGH RADIANCE & HIGH SPEED INFRARED SMD LED		940nm	80	120	Po (mW/sr) @100mA	40°
	APTR3216SF3C-100MAV 3.2X1.6MM (1206) HIGH RADIANCE & HIGH SPEED INFRARED REVERSE MOUNT SMD LED		940nm	8	11	Po (mW/sr) @100mA	140°
