The AP3025PD2BT Photodiode delivers superior light-collection efficiency and high-sensitivity infrared detection in a compact 3.0 x 2.5 x 1.1 mm surface-mount package. Featuring a significantly larger die and expanded active area compared to standard 0805 photodiode packages, this device maximizes photocurrent output and optical coupling efficiency—making it an ideal upgrade for designs requiring higher sensitivity without sacrificing layout flexibility.
Featuring an integrated black diffused lens with a daylight filter, the AP3025PD2BT effectively blocks ambient visible light interference (operating across a spectral bandwidth of 670 nm to 1070 nm with peak sensitivity at 940 nm).
Designed to seamlessly pair with Kingbright's IR emitter series—including APD3224SF7C (850 nm), AM2520SF6C09 (860 nm), APD3224SF4C (880 nm), APTD1608F3C (940 nm), and APD3224F3C (940 nm)—it provides high-signal reliability for dense, precision-sensing applications.
Supplied in Tape & Reel packaging (2,000 pcs/reel), the AP3025PD2BT is optimized for high-speed automated assembly. It carries a Moisture Sensitivity Level (MSL) 3 rating, is Halogen-Free, and fully RoHS compliant.
| Photo | Part Number | Description | Color | Wavelength | Min. | Typ. | Unit | Viewing Angle | Data Sheet | 3D Spec†|
|---|---|---|---|---|---|---|---|---|---|---|
 | AP3025PD2BT | 3.0X2.5MM PHOTODIODE SMD LED | N/A | N/A | N/A | N/A |  |  |
†Lens colors in 3D files are for display purpose only, please refer to Datasheet for precise lens type and color.
†In case of discrepancy, dimensions in 2D PDF files supersede data in 3D specification files.
