0201 Chip SMD-0.6X0.3mm

Sort by
PhotoPart Number / DescriptionWavelength / ColorLuminous IntensityViewing
Angle
Data Sheet3D Spec
Min.Typ.Unit
APG0603CGC-TT
0.6X0.3MM GREEN SMD LED
571nm615mcd @10mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP
APG0603PBC-TT-5MAV
0.6X0.3MM BLUE SMD LED
467nm1525mcd @5mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP
APG0603RWF-TT-5MAV
0.6X0.3MM WHITE SMD LED (X=0.31, Y=0.31)
Cool White30100mcd @5mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP
APG0603SEC-E-TT
0.6X0.3MM RED SMD LED
624nm1540mcd @10mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP
APG0603SEC-TT
0.6X0.3MM ORANGE SMD LED
605nm2050mcd @10mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP
APG0603SURC-TT
0.6X0.3MM RED SMD LED
631nm1035mcd @10mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP
APG0603SYC-TT
0.6X0.3MM YELLOW SMD LED
589nm1030mcd @10mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP
APG0603VGC-TT-5MAV
0.6X0.3MM GREEN SMD LED
527nm3080mcd @5mA140°Data sheet.SLDPRT   .PRO
.IGES   .STEP

Only a portion of Kingbright's product information is available on this website. Please contact Kingbright for any unfound or custom-made items.

† For all 3D specs viewing, save files in local drive and open with your 3D application.
† Lens colors in 3D files are for display purpose only, please refer to Datasheet for precise lens type and color.
† In case of discrepancy, dimensions in Datasheet supersede 3D spec.
